PXR-10(K)-THN Series
Low Profile Keypad Reader
- Stylish and ultra-slim appearance design looks morden, exquisite, and elegant.
- Provides different communication interfaces (Wiegand or T2) for choice to work with controllers.
- IP65 rated ingress protection, suitable to install indoor and outdoor environments.
- Wide range of operating temperature to meet the requirments of tropical or frigid zone climate environment.
- Equipped with a 12-key touch keypad with blue backlight.
Specification：
| Read Format | EM (125 KHz) or MIFARE® (13.56 MHz) |
| Comm. Interface | T2 / Wiegand (More information, please refer to Order Information) |
| Input Ports | 4 (Case Sensor x 1, LED Control x 2, Buzzer x 1) |
| Ingress Protection | IP65 |
| Power Input | DC 12V / 1A |
| Current Consumption | 300mA (max.) |
| Operating Temp. | -20° C~70° C / -4° F ~ 158° F |
| Relative Humidity | 20% ~ 80% (Non-condensing) |
| Dimension | 86mm(L) x 86mm(W) x 15mm(H) |
Product Information：
| Model | Description | Donwloads |
| PXR-10EW-THN | Support Wiegand，EM (125 KHz) Low Profile Reader |  |
| PXR-10EWK-THN | Support Wiegand，EM (125 KHz) Low Profile Keypad Reader | |
| PXR-10ET-THN | Support T2，EM (125 KHz) Low Profile Reader | |
| PXR-10ETK-THN | Support T2，EM (125 KHz) Low Profile Keypad Reader | |
| PXR-10MW-THN | Support Wiegand，MIFARE®(13.56MHz) Low Profile Reader | |
| PXR-10MWK-THN | Support Wiegand，MIFARE®(13.56MHz) Low Profile Keypad Reader | |
| PXR-10MT-THN | Support T2，MIFARE®(13.56MHz) Low Profile Reader | |
| PXR-10MTK-THN | Support T2，MIFARE®(13.56MHz) Low Profile Keypad Reader | |
